Silverstone Technology Lucid Series 3 Sided Tempered Glass Stainless Steel Designed Micro-ATX/Mini-ITX Case with White Trim

SilverStone created the Lucid series in an attempt to combine SilverStone?s traditionally excellent engineering quality with transparent or ?lucid? aesthetics of glass-based exterior. LD01, as the first Lucid series chassis, achieves this objective in splendid fashion. The striking exterior is covered in tempered glass flanked by functional stainless steel bands that not only adds a touch of premium feel but also protect the glass and simplify installation. With inverted motherboard tray design taken from the Temjin TJ08-E, one of the best Micro-ATX cases ever released, graphics or expansion cards installed into the LD01 can intake fresh air from above the chassis for vastly superior cooling compared with traditional layout that has the PSU & drive cage shroud limiting airflow. Another benefit of the inverted layout is that graphics card supporter will make contact only with graphics card's backside, thus eliminate potential interference with graphics card fans. Other notable features the LD01 has include front USB Type-C connector, quick access dust filter, smart backside cable routing, highly flexible space for installing all popular core components, and support for multiple cooling configurations. There are five total 120 / 140mm fan slots around the case with maximum radiator support at front, top, and rear. For those looking for a compact, beautiful glass design in Micro-ATX form factor without compromises, the LD01 is the clear and lucid choice.

ï¿­ Three-sided tempered glass and stainless steel design

ï¿­ Graphics card holder included prevents card bending

ï¿­ Supports up to two 240 / 280mm radiators

ï¿­ Includes front mounted USB 3.1 Gen1 Type-C port

ï¿­ Easily accessible removable filters for dust reduction

ï¿­ Super clean internal look with PSU and drive bay cover

ï¿­ Flexible hard drive bracket can be repositioned to fit radiator or big power supply

Model No.	SST-LD01
	--
	--
	--
Material	Tempered glass & stainless steel panels, steel body
Motherboard	Micro-ATX, Mini-DTX, Mini-ITX
Drive bay	External	--
		--
	Internal	3.5 x 3 (compatible with 2.5) , 2.5 x 2
Cooling system	Front	2 x 120 / 140mm fan slot
	Rear	1 x 120mm fan slot
	Side	--
	Top	2 x 120 / 140mm fan slot
	Bottom	--
	Internal	--
Radiator support	Front	120mm / 140mm / 240mm / 280mm x 1*
	Rear	120mm x 1
	Top	120mm / 140mm / 240mm / 280mm x 1*
	Bottom	--
Expansion slot	5
Front I/O port	USB 3.0 Type-A x 2, USB 3.1 Gen1 Type-C x 1 Audio x 1 MIC x 1
Power supply	Optional PS2(ATX)
Expansion card	Depends on the front radiator and fan thickness, Compatible up to 14.5 (370mm) in length, width restriction ?6.85 (174mm)
Limitation of CPU cooler	168mm
Limitation of PSU	160 ~ 220mm
Net weight	7.45kg
Dimension	218mm (W) x 390mm (H) x 431mm (D), 36.6 Liters 8.58 (W) x 15.35 (H) x 16.97 (D), 36.6 Liters



Remark

* For 280mm radiators and fans, we recommend total thickness of 55mm or less
