Fractal Design Define XL Black Pearl Full Tower Computer Case Fractal Design Define XL Black Pearl Full Tower Computer Case
Fractal Design Define XL Black Pearl Full Tower Computer Case Fractal Design Define XL Black Pearl Full Tower Computer Case
Fractal Design Define XL Black Pearl Full Tower Computer Case
Fractal Design Define XL Black Pearl Full Tower Computer Case
Steel

Fractal Design Define 7 XL Full Tower Computer Case

Fractal Design

FD-C-DEF7X-03

Fractal Designs Define 7 XL Light Tempered Glass. The Define 7 XL sets a new standard for what you should expect from a full tower case in terms of modularity, flexibility and ease of use. New chassis design opens up to fully expose the case interior. Anodized aluminum front panel with reversible dual-handed hinges. Mount up to 18 HDD/SSDs plus five SSDs in the Storage Layout.

Found a better price? Let us know and we'll try and match it!
Estimate shipping
2 in stock
$260.99
Shipping calculated at checkout.

Pickup available at Performance-PCs.com

Usually ready in 1 hour

  • 99% of orders ship same day M-F!
  • FREE Shipping Possible!
  • All-Star CS Team
  • 30-Day Hassle Free Returns
Details

Define 7 XL Light Tempered Glass

The Define 7 XL sets a new standard for what you should expect from a full tower case in terms of modularity, flexibility and ease of use.

  • â?¢ New chassis design opens up to fully expose the case interior
  • â?¢ Anodized aluminum front panel with reversible dual-handed hinges
  • â?¢ Mount up to 18 HDD/SSDs plus five SSDs in the Storage Layout
Features














Plenty of room for massive builds




  • Use the Open Layout for more headroom and gargantuan water-cooling with radiators up to 480 mm in front or top and 280 mm in the base




  • Spacious, extensively adaptable dual-layout interior easily accommodates large motherboards up to E-ATX and SSI-EEB




  • Two 5.25â? ODD bays can be converted to an additional front fan mount with filtered louver covering




  • Ventilated PSU shroud with two-part removable cover




  • Ultra-slim Nexus+ 2 fan hub connects up to three PWM fans and six 3-pin fans


























Superlative storage possibilities




  • Mount up to 18 HDD/SSDs plus five SSDs in the Storage Layout (6 HDD/SSD trays + 2 SSD brackets + 2 multi-brackets included)




  • Detachable PSU cable shield and integrated cable guides with Velcro straps further simplify cable management behind the board




  • Sturdy new HDD cage design with vibration damped trays




  • 13 pass-through holes with ten rubber grommets and two removable covers make for clean cable routing regardless of motherboard size























Airflow and cooling




  • Outstanding cooling capacity with a total of 9 x 140 mm or 11 x 120 mm fan mounts and three preinstalled Dynamic X2 GP-14 fans




  • Easy-to-clean high airflow nylon filters with full PSU coverage and convenient front access




  • The two 5.25 ODD bays can be converted to an additional front fan mount with filtered louver covering























USB Type-C


USB 3.1 Gen 2 Type-C with fast charging support and speeds up to 10Gbps







SSI-EEB


Easily holds your SSI-EEB motherboard







Moduvent


Top panel effortlessly swaps from sound damped solid steel to filtered ventilation
Specifications





  • 3.5/2.5 Universal drive brackets

    6 + 2 included, 18 positions total



  • Dedicated 2.5 drive brackets

    2 included, 5 positions total



  • 5.25â? drive mounts

    2



  • Expansion slots

    9 + 3



  • Front ports

    1 x USB 3.1 Gen 2 Type-C, 2 x USB 3.0, 2 x USB 2.0, Audio I/O, Power button, Reset button



  • Total fan mounts

    11 x 120 mm or 9 x 140 mm



  • Front fan

    4 x 120 mm or 3 x 140 mm, (2 x Dynamic X2 GP-14 included)



  • Top fan

    4 x 120 mm or 3 x 140 mm



  • Rear fan

    1 x 120/140 mm, (1 x Dynamic X2 GP-14 included)



  • Bottom fan

    2 x 120/140 mm



  • Dust filters

    Top, 2 x Front, Bottom + PSU



  • Fixed velcro straps

    Yes



  • Cable routing grommets

    Yes



  • Captive thumbscrews

    HDD brackets, SSD brackets, PSU bracket



  • Left side panel

    Tempered glass



  • Right side panel

    Industrial sound-damped steel







Compatibility






  • Motherboard compatibility

    E-ATX / ATX / mATX / mITX / EE-ATX / SSI-CEB / SSI-EEB



  • Power supply type

    ATX



  • PSU max length

    250 mm (both HDD cages installed)



  • GPU max length

    Storage layout: 359 mm - Open layout: 549 mm (524 mm w/ front fan)



  • CPU cooler max height

    185 mm



  • Front radiator

    Up to 480/420 mm



  • Top radiator

    Up to 480/420 mm



  • Rear radiator

    120 mm



  • Bottom radiator

    Up to 240/280 mm



  • Cable routing space

    30 mm







Dimensions






  • Case dimensions (LxWxH)

    604 x 240 x 566 mm



  • Case dimensions w/o feet/protrusions/screws

    590 x 240 x 548 mm



  • Package dimensions (LxWxH)

    646 x 357 x 708 mm



  • Net weight

    16.64 kg



  • Package weight

    18.84 kg







Other






  • Package contents

    Define 7 XL - Accessory box - User manual - Ventilated top panel - ODD bracket - ODD bay cover - 2 x HDD/SSD trays



  • EAN

    7340172702054



  • UPC

    843276102050



  • JAN

    4537694274302



  • Product code

    FD-C-DEF7X-02
