EVGA 750 GQ, 80+ GOLD 750W, Semi Modular Power Supply

EVGA

210-GQ-0750-V1

Introducing the latest in the EVGA power supply line-up; the GQ series. These power supplies take some of the best features from EVGA's award winning power supplies, like EVGA ECO fan mode for near silent operation

Found a better price? Let us know and we'll try and match it!
Estimate shipping
3 in stock
$129.99
Shipping calculated at checkout.

Pickup available at Performance-PCs.com

Usually ready in 1 hour

  • 99% of orders ship same day M-F!
  • FREE Shipping Possible!
  • All-Star CS Team
  • 30-Day Hassle Free Returns
Details

width=979
Features

width=816
Specifications


CABLE LENGTH





































ATX Cable 1x 600mm (m)
EPS Cable 2x 650mm (m)
PCIe Cable 2x 650mm, 750mm, 2x 650mm (m)
SATA Cable 3x 550mm, 650mm, 750mm (m)
Four-Pin Peripheral Cable 1x 550mm, 650mm, 750mm (m)
Floppy Adapter 1x 100mm (m)
AC Power 1x 1500mm (m)
Modular Cable Type Semi-Modular

CONNECTOR QUANTITY





























24 Pin ATX 1x
EPS (CPU) 2x 8pin (4+4)
PCIe 6x 8pin (6+2)
SATA 9x
Four-Pin Peripheral 3x
Floppy 2x


POWER SPECS







































AC Input 100 - 240 VAC, 10A, 50 - 60 Hz
Rail +3.3V +5V +12V +5Vsb -12V
Max Output 24A 24A 62.4A 3A 0.5A
748.8W
120W 748.8W 15W 6W
Total 750W @ +50C


ADDITIONAL DETAILS





































Operating Temperature 0° to 50° C
Japanese Capacitors 100%
ECO Mode Yes
MTBF 100,000 Hours
Net Weight 7 lbs
Size 85mm (H) x 150mm (W) x 165mm (L)
Approvals TUV, CB, CE, FCC, RCM, cTUVus, BSMI, CCC, WEEE, RoHS
Compliance with ErP Lot 6 2013 Requirement
Fan Size / Bearing 135mm Fluid Dynamic Bearing



Product Warranty


This product comes with a 5 year limited warranty with registration.
EVGA offers several warranty solutions for our customers to choose from. Please refer to the suffix of the part number and our Warranty Terms for details.
