Cooler Master MasterBox NR600

The Master Box NR600 applies optimal cooling and expandability to a minimalist, subtle design. With thermal capability at the forefront of features, the front panel and top panel are designed to signify airflow performance in its purest form.

Form & Function Streamlined

The MasterBox NR600 applies optimal cooling and expandability to a minimalistic design. With thermal capability at the forefront of features, the front panel and top panel are designed to signify airflow performance in its purest form.

Functionality is blended to a compact design by maximizing use of internal space and implementing subtle design elements. The MasterBox NR600 features a tempered glass side panel, fastened by thumbscrews on the rear panel, to keep the surface immaculately flush.

• Minimalistic mesh design


• Optimal thermal performance


• Flush tempered glass side panel design


• Graphics card support up to 410 mm


• Dual audio-microphone headphone jack

Flush Tempered Glass Side Panel Design
The tempered glass side panel, fastened by thumbscrews on the rear panel, keeps the surface flush and unobstructed.

Optimal Thermal Performance
The full mesh front panel and ventilated top panel provide a high potential for thermal performance.

Fan and Radiator Support
Support for the following fan/radiator form factors: FRONT 120/140/240/280/360 mm radiator, 120 mm x 3 fans, 140 mm x 2 fans, TOP 120/240 mm radiator, 120/140 mm x 2 fans, REAR 120 mm radiator, 120 mm x 1 fan.

Dual Audio-Microphone Headphone Jack
The single 4 pole headset jack features both audio and microphone capabilities simultaneously so that separate jacks are not needed.

Drive Bay Support
Supports 4 x 3.5 HDDs and 5 x 2.5 SSDs.

Component Clearances
Supports GPUs under 410 mm, CPU coolers under 166 mm, and PSUs under 180 mm.

Technical Information

• Motherboard Supported:   ATX


• Motherboard Supported:   EATX


• Motherboard Supported:   Micro ATX


• Motherboard Supported:   Mini ITX


• Number of Fans Installed:   3


• Installed Fan Size:   4.72

Bays

• Number of Internal 3.5 Bays:   2


• Number of Internal 2.5 Bays:   2


• Number of Total Expansion Bays:   4

I/O Expansions

• Number of Total Expansion Slots:   7

Interfaces/Ports

• Total Number of USB Ports:   2


• Total Number of Audio In Ports:   1


• Total Number of Audio Out Ports:   1

Power Description

• Power Supply Installed:   No


• Number of Power Supplies Supported:   1


• Number of Power Supplies Installed:   0

Physical Characteristics

• Color:   Black


• Material:   Mesh


• Material:   Steel


• Material:   Plastic


• Material:   Tempered Glass


• Form Factor:   Mid-tower


• Height:   18.7


• Width:   8.8


• Depth:   19.7


• Weight (Approximate):   22.93 lb
